Precision Mechanical Machine Vise
► Mechanical power can be applied separately, simultaneously, or in parallel.
► The down-thrust semi-spherical segment mechanism eliminates jaw lifting and workpiece tilt.
► The slide and sliding surfaces are precision ground.
► Manufactured from JIS FCD60 ductile iron (60 kgf/mm² / 80,000 psi).
► The vise bed is flame-hardened to HRC 45 to ensure long-lasting wear resistance and accuracy.
► The down-thrust semi-spherical segment mechanism eliminates jaw lifting and workpiece tilt.
► The slide and sliding surfaces are precision ground.
► Manufactured from JIS FCD60 ductile iron (60 kgf/mm² / 80,000 psi).
► The vise bed is flame-hardened to HRC 45 to ensure long-lasting wear resistance and accuracy.
